A36 Angle Bar
A36 Angle Bar is a kind of carbon steel angle that is widely used in various construction and engineering projects. Angle Bar is also known as L-shaped cross-section or L-bar. It is formed by bending a single piece of A36 steel into a 90-degree angle. Angle Bar has two legs of equal or unequal length and width. Angle Bar can be either hot-rolled or cold-formed, depending on the production method and the desired shape.
Usage
Angle Bars are used in a variety of applications due to their versatility and strength, including:
- Building Construction: As supportive elements in building frames, doorways, and window frames.
- Industrial Projects: In shelving, benches, and supports within workshops and warehouses.
- Infrastructure: For bridges, support beams, and other structural components in public works.
- General Fabrication: Ideal for custom projects, including brackets, frames, and other structural elements.
Chemical Composition
|
Chemical Composition (%) |
Carbon |
Manganese |
Phosphorus |
Sulfur |
Silicon |
|
A36 Angle Bar |
0.26 max |
0.80-1.20 |
0.04 max |
0.05 max |
0.40 max |
|
Mild Steel Angle Bar |
0.25 max |
0.60-0.90 |
0.04 max |
0.05 max |
0.40 max |
|
Stainless Steel Angle Bar |
0.08 max |
2.00 max |
0.045 max |
0.030 max |
1.00 max |
Mechanical Properties
|
Mechanical Properties |
Yield Strength (MPa) |
Tensile Strength (MPa) |
Elongation (%) |
|
A36 Angle Bar |
250 min |
400-550 |
20 min |
|
Mild Steel Angle Bar |
250 min |
400-550 |
20 min |
|
Stainless Steel Angle Bar |
205 min |
515 min |
40 min |
Product Specifications
|
Type: |
ASTM A36 Angle Bar |
|
ASTM standard: |
A36 |
|
Specification: |
20*20–250*250 |
|
Thickness: |
2MM-20MM |
|
Length: |
6M 9M 12M (cutting to meet your requirment) |
|
Material: |
Carbon steel |
|
Surface treatment: |
Black and Galvanized |
|
Grade: |
Q195, Q235, Q345 (Chinese standard) |
|
Zinc Thickness: |
35~85 micron |
|
Process for reference: |
Punching |
|
General Usage: |
Curtain wall, warehouse, greenhouse, ect. |
Advantage
- Strength and Durability: A36 steel is known for its durability and resistance to wear, making it suitable for long-term structural use.
- Versatility: Can be used in a wide range of applications, both in construction and industrial projects.
- Ease of Fabrication: A36 steel is easy to weld, cut, and machine, facilitating quick and efficient construction.
- Cost-Effectiveness: Offers a great balance between performance and affordability, making it a popular choice for various projects.
Angle Bar in China
In China, the production of Angle Bar is marked by advanced manufacturing processes and adherence to international standards. Chinese steel manufacturers use state-of-the-art technology to ensure high-quality, durable angle bars that meet the needs of various industries. The combination of quality, efficiency, and competitive pricing makes Chinese A36 Angle Bars a preferred option for both domestic and international customers.
Hot Tags: a36 angle bar, China a36 angle bar manufacturers, factory, angle bar for sprockets, angle bar for cranks, angle bar for tools, angle bar for pulleys, angle bar for fixtures, angle bar for belts
