Metal Rectangle Tube

Metal Rectangle Tube, also known as metal rectangular tubing, is a hollow metal product that has a rectangular cross-section. It is made of various metals, such as steel, aluminium, copper, brass, etc. It has many advantages over other types of metal products, such as high strength, low weight, corrosion resistance, and aesthetic appeal.
Send Inquiry
Product Introduction

Metal Rectangle Tube, also known as metal rectangular tubing, is a hollow metal product that has a rectangular cross-section. It is made of various metals, such as steel, aluminium, copper, brass, etc. It has many advantages over other types of metal products, such as high strength, low weight, corrosion resistance, and aesthetic appeal. It is widely used in various industries and projects, such as construction, engineering, automotive, furniture, etc.






Product Highlights



  • Customize in different sizes, shapes, grades, and finishes, according to the customer's requirements and specifications.
  • Easily welded, cut, drilled, bent, and formed, which provides flexibility and convenience for installation and fabrication.
  • Coat with various materials, such as paint, powder, galvanizing, etc., to enhance its protection and appearance.
  • Recycl and reus, which reduces the environmental impact and the cost.



Product Details



The following table shows the chemical composition and mechanical properties of some common Metal Rectangle Tubes, according to the ASTM standards.

Metal

Element

Tensile strength

Yield strength

Elongation

Steel A500

C 0.26% max, Mn 1.35% max, P 0.035% max, S 0.035% max

400 MPa

250 MPa

0.23

Steel A513

C 0.15% max, Mn 0.6% max, P 0.035% max, S 0.04% max

379 MPa

310 MPa

0.1

Aluminium 6061

Al 95.8-98.6%, Si 0.4-0.8%, Mg 0.8-1.2%, Cu 0.15-0.4%, Cr 0.04-0.35%

310 MPa

276 MPa

0.12

Aluminium 6063

Al 97.5%, Si 0.2-0.6%, Mg 0.45-0.9%, Fe 0.35% max, Cu 0.1% max

241 MPa

152 MPa

0.12

Copper C12200

Cu 99.9%, P 0.02%

248 MPa

69 MPa

0.45

Brass C26000

Cu 68.5%, Zn 31.5%

427 MPa

124 MPa

0.57



The following table shows the nominal dimensions and weights of some common Metal Rectangle Tubes, according to the ASTM standards.

Metal

Nominal size

Outside diameter

Wall thickness

Weight per foot

Steel A500

3 x 2 inch

3.000 x 2.000 inch

0.1875 inch

4.32 lb

Steel A513

4 x 2 inch

4.000 x 2.000 inch

0.1875 inch

5.62 lb

Aluminium 6061

2 x 1 inch

2.000 x 1.000 inch

0.125 inch

1.28 lb

Aluminium 6063

3 x 1.5 inch

3.000 x 1.500 inch

0.125 inch

1.92 lb

Copper C12200

2 x 1 inch

2.000 x 1.000 inch

0.065 inch

1.66 lb

Brass C26000

3 x 1.5 inch

3.000 x 1.500 inch

0.065 inch

2.49 lb



Product Benefits



  • Meet the diverse needs of customers, as it can be used for various purposes, such as structural support, framing, railing, fencing, shelving, furniture, etc.
  • Save the transportation and installation costs, as it can be delivered in bundles or coils, and it can be connected by welding, bolting, or clamping.
  • Improve the safety and reliability of the product, as it can be tested and inspected before and after the production, and it can be certified by various standards and organizations.
  • Enhance the aesthetic and functional value of the product, as it can be designed and finished in different styles and colors.



Product Instructions



  • Store in a dry and clean place, away from fire and corrosive substances.
  • Check before use, and any defects or damages should be reported and repaired.
  • Install according to the design drawings and specifications, and the joints should be sealed and tested.
  • Operate and maintaine according to the instructions and regulations, and any problems or malfunctions should be reported and solved.






Customer Service



  • We have a professional sales team that can provide you with the best quotation and consultation for Tube.
  • We have a skilled production team that can ensure the quality and quantity of Tube.
  • We have a fast delivery team that can deliver Metal Rectangle Tube to your destination in time and in good condition.
  • We have a friendly after-sales team that can provide you with the installation guidance, technical support and warranty service for our product.
  • We have a FAQ section that can answer some of your common questions about our product.






Why Choose Us



  • We are a leading manufacturer and supplier of Square Galvanized Tubing in China, with more than 20 years of experience and expertise.
  • We have a modern and advanced production facility, with a monthly output of 50,000 tons of Square Galvanized Tubing.
  • We have a strict quality control system, with a ISO 9001, ASTM, and API certification.
  • We have a loyal and stable customer base, with a long-term cooperation with many well-known companies and projects in the world.
  • We have a competitive and reasonable price, with a flexible and negotiable payment term.
